Commercial Water Softeners
State of the Art Commercial Water Softeners
Our commercial water softeners treat city water supplies, well water systems, or surface water supplies. These state-of-the-art systems with their advanced electronics can be incorporated in a multitude of configurations. Single through six unit configurations are available from the same electronic platform. They are designed for complex uses, yet easy to operate and maintain. It's “plug and play” accessories make even the most demanding applications a simple choice for the toughest job. No hard water bypass, separate source regeneration, and brine reclaim is all made easy. The robustly constructed valve with a fully assembled “stack” and piston design allows for years of reliable operation.
Features & Options
Robust filtration systems designed to withstand the harshest industrial environments. Engineered for maximum water quality and operational reliability.
Features
- Up to six metered units in multiple configurations
- Top-mounted valves for ease of use
- Full adjustable cycling of regeneration
- Alternate Cycle Sequencing (patented)
- Water Efficient Technology (WET)
- High-capacity virgin polystyrene resin
- Corrosion-resistant mineral tanks made from fiberglass-reinforced polyester
- IQ2 technology
- Highly functional diagnostics
- NSF®-certified components
- Progressive flow (Optional)
- Headers and skid mounting (Optional)
- Separate source regeneration (Optional)
- ASME tanks (18" and larger) (Optional)
- Salt reclaim systems (Optional)
- System controller
Markets
- Steam Boilers
- Apartments & Condos
- Assisted Nursing Facilities
- Boiler feeds
- Cafeterias
- Casinos
- Corporate Campuses
- Farms
- Food Service
- Hospitals
- Hospitality
- Grocery
- Laboratories
- Restaurants
- Reverse Osmosis Feed
- Schools & Universities
- Theme Parks
- Vehicle Wash
Optional System Controller
When combined with IQ2 electronics, the system controller operates up to six units. The system diagnostics include real-time 90-day water usage, peak flow rate, totalizer, and much more. This information is downloadable to a USB drive or viewable as live information with an Ethernet connection.
With its battery backup, processor, and enclosure, information is held safe and secure. The controller’s display indicates a multitude of information at first glance including LED status indicators for online, standby, and regeneration modes.
Controllers
Each individual controller features IQ2 technology, which includes history and diagnostic information. C43 controllers are capable of “plug and play” technology, which incorporates no hard water bypass and separate source regeneration.
The 1” and 1.25” control valves are manufactured from Noryl® and offer extremely high flow rate characteristics. The 1.5” through 3” controllers feature solid lead-free brass construction and stainless steel meters.
All C43 systems feature one-piece cartridge and piston design for ease of service.
